| Output Power: |
2500 Watts single tone continuous |
| HF Bands: |
160m to 10m (assuming resistive load) |
| Tuning: |
Three controls |
| Antenna switching: |
10 Amp RF 6 position mode switch for multiple antennas |
| Capacitor: |
low minimum custom variable capacitor; 460pF@6 kV |
| Roller inductor: |
10 Amp silver-plated inductor wheel shaft and contact wheel on polyresin-fiberglass body |
| Impedance: |
matching range 20 Ohms to 1500 Ohms |
| Metering: |
Active crossneedle Peak/Peak Hold with backlighting |
| Meter power range: |
0-300 Watts/
0-3000 Watts |
| Balun: |
Ferrite 1:1 inpupt balun |
| Output: |
Unbalanced/Balanced activated by front panel switch |
| Chassis: |
.090 ga. aluminium gold iridite coated |
| Top cover: |
.090 ga. aluminium powder coated |
| Front cover: |
.090 ga. aluminium powder coated |
| Dimensions: |
15 1/8" wide x 7 5/8" high x 19" deep |
| Shipping weight: |
20 lbs |
| |
| Warranty: |
One year |
