| Output Power: |
2000 Watts PEP |
| HF Bands: |
160m to 6m (assuming resistive load) |
| Tuning: |
Three controls |
| Antenna switching: |
6 position mode switch for multiple antennas |
| Capacitor: |
low minimum custom variable capacitor; 15pF - 400pF@4.5 kV |
| Roller inductor: |
silver-plated inductor wheel shaft and contact wheel on ceramic body |
| Impedance: |
matching range 15 Ohms to 1500 Ohms |
| Metering: |
Active crossneedle Peak/Peak Hold with backlighting |
| Meter power range: |
0-300 Watts/
0-3000 Watts |
| Power Input: |
12 VDC 200 mA
Power cable supplied
Requires power supply |
| Balun: |
Optional external 1:1 or 4:1 current |
| Chassis: |
.090 ga. aluminium gold iridite coated |
| Top cover: |
.090 ga. aluminium powder coated |
| Front cover: |
.090 ga. aluminium powder coated |
| Dimensions: |
14.5" wide x 5" high x 13.5" deep |
| Shipping weight: |
14 lbs |
| |
| Warranty: |
One year |
