AT2KD

Output Power: 2000 Watts PEP
HF Bands: 160m to 6m (assuming resistive load)
Tuning: Two controls
Antenna switching: 6 position mode switch for multiple antennas
Capacitor: Differential with 2 stators and 1 rotor; 13pF - 420pF@5kV
Roller inductor: silver-plated inductor wheel shaft and contact wheel on ceramic body
Impedance: matching range 20 Ohms to 1200 Ohms
Metering: Active crossneedle Peak/Peak Hold with backlighting
Meter power range: 0-300 Watts/
0-3000 Watts
Power Input: 12 VDC 200 mA
Power cable supplied
Requires power supply
Balun: Optional external 1:1 or 4:1 current
Chassis: .090 ga. aluminium gold iridite coated
Top cover: .090 ga. aluminium powder coated
Front cover: .090 ga. aluminium powder coated
Dimensions: 13.2" wide x 5.75" high x 12" deep
Shipping weight: 12 lbs

Warranty: One year
