| Output Power: |
600 Watts PEP SSB; 500 Watts CW |
| HF Bands: |
6m to 160m |
| Tuning: |
Two controls |
| Antenna switching: |
6 position mode switch for multiple antennas |
| Capacitor: |
differential tuning with 2 stators and 1 rotor; 14pF - 360pF@2.5kV |
| Roller inductor: |
15uH ceramic body |
| Outputs: |
balanced and unbalanced lines |
| Impedance: |
matching range 20 Ohms to 1500 Ohms |
| Metering: |
Active crossneedle Peak/Peak Hold with backlighting |
| Meter power range: |
0-300 Watts/0-1000 Watts |
| Balun: |
4:1 current |
| Chassis: |
.090 ga. aluminium gold iridite coated |
| Top cover: |
.090 ga. aluminium powder coated |
| Front cover: |
.090 ga. aluminium powder coated |
| Dimensions: |
10 3/8" wide x 5 1/2" high x 12 7/8" deep |
| Shipping weight: |
8 lbs |
| |
| Warranty: |
One year |
